Tait TB8100 Service Manual

TB8100 Service Manual Power Amplifier Fault Finding 129
© Tait Electronics Limited September 2006
8.2 Identifying the PA
You can identify the model and hardware configuration of a PA by referring
to the product code printed on labels on the heatsink and rear of the cover.
The meaning of each character in the product code is explained in the table
below.
Note This explanation of PA product codes is not intended to suggest
that any combination of features is necessarily available in any one
PA. Consult your nearest Tait Dealer or Customer Service
Organisation (CSO) for more information regarding the availabil-
ity of specific models and options.
Product Code Description
TBAX
XXX-XXXX 7 = 5W
8 = 50W
9 = 100W
TBAXXXX-XXXX 0 = default
1 = 12V PA
TBAXXXX
-XXXX Frequency Band and Sub-band
B1 = 136MHz to 174MHz
C0 = 174MHz to 225MHz
H0 = 380MHz to 520MHz
a
K2 = 760MHz to 870MHz
b
L0 = 850MHz to 960MHz
c
a. Only PAs with hardware version 00.02 and later can operate from 380MHz to
520MHz. PAs with hardware version 00.01 and earlier can only operate from
400MHz to 520MHz.
b. The actual frequency coverage in this band when used with a K-band TB8100 reciter
is 762MHz to 776MHz, and 850MHz to 870MHz.
c. The actual frequency coverage in this band when used with an L-band TB8100 reciter
is:
852MHz to 854MHz and 928MHz to 930MHz
927MHz to 941MHz (transmit only)
TBAXXXX-XXXX 0 = default
TBAXXXX-XX
XX 0 = default
TBAXXXX-XXX
X 0 = default
TBAXXXX-XXXX
0 = default
