152 Power Amplifier Fault Finding TB8100 Service Manual

7. Measure the FINALX

-BIAS-MICRO voltage of the final

transistor(s) at the following test points:

■ 50W PA pin 2 of SK106

■ 100W PA final 1 pin 2 of SK105

■ 100W PA final 2 pin 2 of SK107.

The voltage should be 4V (typical). If it is, go to “6W Board” on

page 155. If it is 0V, replace the control board. If it is greater than

0V, but less than 4V (typical), go to “60W Board” on page 162.

1. X = final 1 or final 2.
