TB8100 Service Manual Power Amplifier Fault Finding 159

Table 8.2 Test point voltages on the 6W board

Test

Point Pin Pin Name Voltage Notes

SK101 1 & 4 GND ground

2 & 3 +28V-FILT1 26V to 30V filtered supply

SK102 1 POWER-CONTROL-CONT <0.5V analogue voltage

2 RF detect <0.8V RF drive present, +11dBm

3 PA-KEY-COAX >4.0V logic level

4 driver temperature digital digital signal, 0V and 5V

SK103 1 standby <0.5V logic level

2 driver current <0.05V current = measured voltage ÷ 2

3 DRIVER-BIAS-CONT <0.05V typical analogue voltage

4 +10V-SWITCHED-CONT 0.05V 10V regulated supply to 6W board

TP101 DRIVER-BIAS-CONT 2.9V to 3.4V

TP206 PIN-BIAS 2V to 2.5V
