Tait TB8100 Service Manual

TB8100 Service Manual Power Amplifier Fault Finding 167
© Tait Electronics Limited September 2006
Table 8.4 Placement of the input coupling components according to frequency band
Band
5W 50W 100W
100W +
Isolator
Component TypeC109 C110 C109 C110 C109 C110 C109 C110
B
✓✓ ✓✓
IPN 018-11820-10 CAP
0603 8p2 50V NPO ±0.1pF
C
✓✓ ✓✓
IPN 018-11820-10 CAP
0603 8p2 50V NPO ±0.1pF
H
✓✓✓ ✓
IPN 018-11330-10 CAP
0603 3p3 50V NPO ±0.1pF
K
✓✓✓ ✓
IPN 015-21100-05 CAP cer
1p0 ±0.1pF 200V 0805
R138/
R139
R145/
R146
R138/
R139
R145/
R146
R138/
R139
R145/
R146
R138/
R139
R145/
R146
L
✓✓✓ ✓
IPN 036-10000-00 RES
0805 0R 1/8W
Table 8.5 Test point voltages on the LPF/directional coupler board
Test Point Pin Name
Tx Off
Voltage
Tx On
Voltage
a
Notes
TP101 FWD-PWR-ANA 0.27V >0.27V analogue voltage, proportional to
forward power
TP102 REV-PWR-ANA 0.27V <0.5V analogue voltage, proportional to
reverse power
TP103 +10V 10V 10V regulated 10V to bias the directional
coupler diodes
TP104 LPF-DC-ROM
(OR to ground)
0V 0V the microprocessor senses this input to
verify the presence of the LPF/
directional coupler board
TP105 GND ground
a. Measured when the PA is set to its rated RF output power (i.e. 5W, 50W, or 100W according to model).
