224 Power Management Unit Fault Finding TB8100 Service Manual

6. If the output voltages are incorrect, recalibrate the PMU as described

in the Calibration Kit documentation and repeat this task. If the

output voltages are now correct, go to Task 3

. If the output voltages

are still incorrect, go to “DC Module” on page 230 or “AC Module”

on page 240, depending on which module is faulty. If the PA output

voltage is correct, and the auxiliary output voltage is incorrect, go to

“Auxiliary Power Supply Board” on page 229.

Table 13.1 Output voltages

Output Voltage Limits

PA 28.0VDC ±0.2V

12V auxiliary

24V auxiliary

48V auxiliary

13.8VDC ±2%

27.6VDC ±2%

54.6VDC ±2%

Default Chapter2
