Takeuchi TB216 User Manual

3-23
OperatiOn
Braking when descending slopes
When descending slopes, the brakes are
applied automatically once the travel levers
are returned to the neutral position.
If the crawler slips
If the crawler slips while climbing a slope and
impossible to travel, use the pulling force of
the arm to climb the slope.
CAUTIONS ON OPERATING
If the engine stops when descending a
slope, set the travel levers to the neutral
position, stop the machine, then start the
engine.
Do not open the door while traveling on
slopes
If the engine stops
Opening the door while traveling on slopes is
dangerous, as the force required to open
and close the door changes abruptly. Always
keep the door closed when traveling on
slopes.

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
