FOREWORD
This manual describes operation, inspection
and maintenance of the machine, as well as
safety instructions to be heeded during these
operations.
If you have any questions about the
machine, please contact a Takeuchi sales or
service outlet.
INTRODUCTION
MANUAL STORAGE COMPARTMENT
A compartment for storing this manual is
provided at the position shown on the
diagram below.
1. Insert the starter key and turn it
counterclockwise to open the cover under
the seat.
2. After using the manual, place it in the
plastic pouch and store it back in the
manual storage compartment.
SERIAL NUMBERS
IMPORTANT: Do not remove the machine
name plate with the serial number.
Check the serial numbers of the machine
and engine and write them down in the
spaces below.
Machine number:
Engine number:
AD6O003

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
