Takeuchi TB216 User Manual

7-3
SpecificationS
<Applicable machine models 216100002 or later>
Type Canopy
MASS
Operating mass kg (lb)
Rubber crawlers 1770 (3900)
Steel crawlers 1820 (4010)
PERFORMANCE
Bucker capacity
(Standard bucket)
m
3
(cu. ft.)
Heaped 0.038 (1.34)
Struck 0.028 (0.99)
Slew speed min
-1
(rpm) 9.2 (9.2)
Travel speed km/h (mph)
Rubber crawlers
1st 2.2 (1.37)
2nd 4.2 (2.61)
Steel crawlers
1st 2.1 (1.30)
2nd 4.0 (2.49)
Gradeability (degrees) 30
Ground pressure kPa (psi)
Rubber crawlers 29.4 (4.26)
Steel crawlers 32.8 (4.76)
Noise level dB (A)
Sound power level L
WA 93
Sound pressure level L
pA —
ENGINE
Manufacturer and model Yanmar 3TNV74
Rated output
Net (ISO 14396) kW/min
-1
(hp/rpm) 11.2/2400 (15.0/2400)
Net (ISO 9249/
SAEJ1349)
kW/min
-1
(hp/rpm) 10.8/2400 (14.5/2400)
Displacement ml (cu.in.) 993 (60.6)
Starter V-kW 12-1.0
Alternator V-kW 12-0.48
Battery (IEC 60095-1) V-A·h 12-45
BASIC SPECIFICATIONS

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
