SpecificationS
MACHINE DIMENSIONS
Canopy
Unit: mm (inch)
Item
Long arm
Rubber crawlers Steel crawlers
A Overall length 3870 (152.3)
B Upperstructure overall width 985 (38.8)
C Overall height
2275 (89.6)*
2255 (88.8)**
2280 (89.8)*
2260 (89.0)**
D Slew radius 1075 (42.3)
E Clearance height under upperstructure 460 (18.0) 465 (18.2)
F Crawler base 1155 (45.6) 1135 (44.7)
G Crawler overall length 1520 (59.9) 1505 (59.3)
H Crawler overall width (narrow) 980 (38.6)
H
2
Crawler overall width (wide) 1300 (51.2)
J Crawler shoe width 230 (9.1)
K Ground clearance of undercarriage 205 (8.0) 210 (8.2)
L Minimum radius of equipment and attachment 1480 (58.2)
M
Minimum radius of equipment at maximum front
offset
1155 (45.4)
P Offset distance of bucket (right swing) 400 (15.7)
Q Offset distance of bucket (left swing) 570 (22.5)
R Dozer blade width (narrow) 980 (38.6)
R
2
Dozer blade width (wide) 1300 (51.2)
S Dozer blade height 310 (12.1)
T Front distance to axis of rotation 2800 (110.2)
U Dozer blade distance to axis of rotation 1200 (47.2)
V Boom swing angle (Left) 80°
W Boom swing angle (Right) 50°
X Overall length (dozer blade at rear) 4040 (159.1)
*: Applicable machine models 216000002 or later
**: Applicable machine models 216100002 or later
