Takeuchi TB216 User Manual

7-9
SpecificationS
Cab
OPERATING RANGES
Unit: mm (inch)
Item
Long arm
Rubber crawlers Steel crawlers
A Maximum reach 4090 (160.9)
B Maximum reach at ground reference plane 4035 (158.9)
C Maximum digging depth 2390 (94.0) 2385 (93.8)
D Maximum vertical digging depth 2060 (81.0) 2055 (80.8)
E Reach at maximum vertical digging depth 2790 (109.9)
F Maximum height of cutting edge 3740 (147.3) 3745 (147.5)
G Maximum dumping height 2705 (106.5) 2710 (106.7)
H Minimum dumping height 755 (29.8) 760 (30.0)
J Dozer blade maximum lifting 360 (14.2) 365 (14.4)
K Dozer blade maximum lowering 365 (14.3) 360 (14.1)
Canopy
Unit: mm (inch)
Item
Long arm
Rubber crawlers Steel crawlers
A Maximum reach 4090 (160.9)
B Maximum reach at ground reference plane 4035 (158.9)
C Maximum digging depth 2390 (94.0) 2385 (93.8)
D Maximum vertical digging depth 2060 (81.0) 2055 (80.8)
E Reach at maximum vertical digging depth 2790 (109.9)
F Maximum height of cutting edge 3740 (147.3) 3745 (147.5)
G Maximum dumping height 2705 (106.5) 2710 (106.7)
H Minimum dumping height 755 (29.8) 760 (30.0)
J Dozer blade maximum lifting 360 (14.2) 365 (14.4)
K Dozer blade maximum lowering 365 (14.3) 360 (14.1)

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
