Takeuchi TB216 User Manual

2-21
Controls
FUNCTION OF EACH KEY
The functions are as below in the Home
screen. The different functions appear in the
other screens.
A. Stopping alarm
Pressing the (A) key stops alarm.
B. Work light/meter switching
· Pressing the (B) key turns on or off the
work light.
· Pressing and holding the (B) key for two
seconds or more each time the display
changes as follows:
1. Hour meter
2. Trip meter 1
3. Trip meter 2
4. Trip meter 3
INSTRUMENT CLUSTER
C. Menu/trip meter reset
· Pressing the (C) key switches to the
Menu screen.
· Pressing and holding the (C) key for
three seconds or more while the trip
meter is displayed returns the trip meter
to “0”.
5. Returns to the hour meter

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
