Replacement Parts
Page 112 ME-45X-01
E-451 & E-457
Throttle Linkage
Item No. Part No. Description Qty
1 01-450-29 Accelerator module mounting bracket 1
2 02-150-11 Extension lever (on module arm) 1
3 50-123-23 Rod, treadle arm to module 1
88-109-81 3/8 NC LOCK NUT 1
88-108-60 3/8 CUT WASHER 1
4 50-481-00 Connector, slip 1
5 88-527-11 Cotter pin 1
THROTTLE LINKAGE
