Drive Axle
Page 44
E-451 & E-457
ME-45X-01
HARDWARE TORQUE
If hardware is not listed here, refer to standard torque
values in the appendix.
Description Foot Pounds Newton Meters
Pinion nut 175 245
Backing Plate to 3rd member 30-45 42-63
Ring Gear Bolts 65-80 91-112
Bearing Cap Bolts (F2) 80-85 112-119
Bearing Cap Bolts (F3) 55-75 77-105
Spanner Lock Bolts 12-25 17-35
IDENTIFY AXLE TYPE
