Front Axle
Page 31
ME-45X-01
E-451 & E-457
REPLACE FRONT WHEEL
BEARINGS
1: Set the park brake.
2: Disconnect the batteries.
3: Raise the front of the vehicle and support with
jack stands.
4: Remove the tire/wheel assembly from the fork.
Refer to Axle Shaft section.
5: Thoroughly clean all grease from the inside of the
hub and the bearings.
6: Inspect and replace the races and bearings as a
set.
Note: If equipped with a dual wheel fork, it is
recommended to replace the bearings in
both wheels at the same time.
7: Assemble in reverse order, using new grease
seals.
8: Reinstall the tire/wheel. Refer to Axle Shaft
section.
a. Pack the bearings with grease.
b. Adjust the bearing preload per specications in
the Adjust Front Wheel Bearing procedure.
9: Lower the vehicle.
10: Reconnect the battery.
11: Remove the blocks from behind the wheels.
12: Test drive the vehicle.
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
AXLE SHAFT, REMOVE/INSTALL
Remove
1: Remove the front axle nut.
2: Slowly raise the front of the vehicle until the axle
can slide freely out of the fork. The front wheel(s)
should still be resting on the ground.
3: Remove the front axle from the fork and support
the vehicle with jack stands.
Note: If the bearings were worn until they were
broken, then the shaft may have to be cut
out of the fork.
4: Inspect the axle shaft and holes in the fork for the
shaft.
• If there is any noticeable wear on the shaft then it
should be replaced.
• The holes in the fork should be round. If worn in an
oval then the fork should be replaced.
Install
1: Raise the front of the vehicle so that the hole for
the axle is the same height as the front wheel
hub.
2: Assemble the bearing spacers into the front
wheel hub and place the front wheel(s) into the
fork.
3: Insert the axle into the front fork.
4: Lubricate the bearings.
5: Install the axle nut(s). Refer to Adjust Front
Wheel Bearings section for information regarding
tightening the front axle.
Note: If your vehicle is equipped with two axle nuts,
the nuts should be tightened equally so that
the same number of axle threads are visible
on both ends of the shaft.
6: Lower the vehicle.
7: Reconnect the battery.
8: Remove the blocks from behind the wheels.
9: Test drive the vehicle.
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
