Batteries
Page 78
E-451 & E-457
ME-45X-01
HARDWARE TORQUE
If hardware is not listed here, refer to standard torque
values in the appendix.
Description Inch Pounds Newton Meters
Battery terminal, Trojan bolt 95-105 11-12
Battery terminal, Trojan stud 95-105 11-12
Battery terminal, T/D bolt 168 19
Individual Batteries
1: Using an insulated wrench, disconnect the cables
from the battery to be removed.
2: Using a battery lifting strap, remove the battery
from the vehicle.
3: Inspect the battery compartment for corrosion. If
there is signicant corrosion, all batteries should
be removed and the compartment cleaned and
painted.
4: Install the battery and torque the battery terminal
hardware per torque listed in the Hardware
Torque table at the end of this section.
Individual batteries can weight up to 80 pounds or
more. To avoid injury, use proper lifting techniques
or a hoist to remove the battery.
WARNING
