Steering
Page 46
E-451 & E-457
ME-45X-01
INSPECT ROD ENDS
Note: A set of ball joints and/or rod ends will wear
at the same rate. If a ball joint and or rod end
is worn out, then all should be replaced as
a set.
1: Visually inspect each rod end for any signs of
play between the ball and the nylon or brass
bushing in the housing.
2: If any play is evident, then the rod end is worn out
and should be replaced. Refer to section Replace
the Ball Joints, Tie Rods, and Drag Link for
information regarding replacing ball joints.
3: Reconnect the battery.
4: Remove the blocks from behind the wheels.
5: Test drive the vehicle.
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
INSPECT FORK BEARINGS
1: Raise the front of the vehicle and support with
jack stands.
2: Inspect for lateral play by attempting to move
the fork to the left and right (not rotating), There
should be no discernible play.
3: If there is any play in the fork bearings, refer to
section Replace the Front Fork for information
regarding adjusting the fork bearings.
4: Lower the front end to the ground.
5: Reconnect the battery.
6: Remove the blocks from behind the wheels,
7: Test drive the vehicle.
