Taylor-Dunn E-451 - Remove;Install; Inspect

Motor Controller
Page 66
E-451 & E-457
ME-45X-01
INSPECT
Inspect the area around all of the terminals for cracked
or separated potting compound.
Inspect the surface of each terminal for corrosion.
Any cracks or corrosion may be an indication that the
terminal seal is broken and may result in premature
failure of the controller.
Check the adjustment screw plugs for correct torque.
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
REMOVE/INSTALL
It may be required to remove the control panel from the
vehicle for this procedure.
Remove
1: Turn the start switch OFF.
2: Disconnect the battery.
3: Using a backup wrench, remove the four terminal
bolts and wires.
4: Disconnect the wires from the KSI and #2
terminals.
5: If equipped with the 7-pin in-line connector,
disconnect it.
6: Remove the four bolts holding the controller to
the panel and remove the controller.
Install
1: Thoroughly clean the controller base and
mounting plate.
2: Install the controller to the mounting plate.
3: Attach the wires to the studs and, using a backup
wrench, torque per specication listed in the
table at the end of this section.
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
Use a backup wrench on the terminal bolts. Failure
to use a backup wrench may result in breaking the
terminal seal and premature failure of the controller.
NOTICE
TROUBLESHOOTING
Troubleshooting the control system is not included in
this manual.
All electrical troubleshooting information is included in
a separate manual “Troubleshooting Electric Vehicles”
part number M7-001-69.
The troubleshooting manual was provided on the original
vehicle documentation CD. A replacement CD or hard
copy can be purchased from your authorized Taylor-Dunn
distributor or can be downloaded from the Taylor-Dunn
web site.
