Drive Motor
Page 63
ME-45X-01
E-451 & E-457
SERVICE LIMITS
This section is one section of a complete service
manual. Before starting any procedure, read all
warnings and instructions that are located in the
Service Guidelines chapter.
WARNING
Motor Specication
Number
Undercut Depth
Commutator
Diameter (min)
Brush Length
(min)
Resistance
(Ohms@75º F)
mm inches mm inches mm inches Armature Field
70-054-00
(BP5-4002)
1.0 0.04 69.9 2.75 16 0.62 0.0016 0.006
