Replacement Parts
Page 93
* Not available at time of printing
ME-45X-01
E-451 & E-457
Rear Axle
Item No. Part No. Description Qty
1 88-100-11 3/8 X 1 NC Hex bolt 8
2 45-301-00 Seal, Large bearing (E-451) 0 or 2
3 32-515-00 Retainer, Large bearing (E-451) 0 or 2
32-509-00 Retainer, Small bearing (E-457) 0 or 2
4 96-331-00 Wheel stud 10
5 41-163-05 Axle, Left (E-451) 0 or 2
41-162-05 Axle, Right, (E-451) 0 or 2
41-163-00 Axle, Left, (E-457) 0 or 2
41-162-00 Axle, Right (E-457) 0 or 2
6 32-514-00 Retainer, axle (E-451) 0 or 2
32-511-00 Retainer, axle (E-451) 0 or 2
7 80-503-00 Bearing, Large (E-451) 0 or 2
80-505-00 Bearing, Small (E-457) 0 or 2
8 45-045-00 Gasket, Large bearing 0 or 2
9 88-109-81 3/8 NC Lock nut 8
Not 32-512-00 Spacer, (behind axle retainer, E-451) 0 or 2
shown
