Replacement Parts
Page 95
* Not available at time of printing
ME-45X-01
E-451 & E-457
Transmission Differential Case
Item No. Part No. Description Qty
44-340-28 Complete 3rd member assembly, Ready to install
1 - 3rd member Housing , Included in #3 1
2 88-119-80 3/8” NF Nut 14
3 44-340-92 Differential kit 1
4 80-128-00 Carrier Bearing Race 2
5 80-512-00 Carrier Bearing 2
6 31-239-00 Ring and Pinion Gear Set 1
7 41-997-00 Oil Plug 3
8 41-290-13 Rear End Housing 1
10 80-554-00 Front Pinion Bearings 2
11 41-711-00 Pinion Housing Shim 1
12 80-702-00 O-Ring 1
13 - Pinion Housing, Included in #3 1
14 16-419-00 .002 Shim (Add Shims As Needed) -
16-420-00 .010 Shim (Add Shims As Needed) -
16-411-00 .005 Shim (Add Shims As Needed) -
15 16-415-00 Spacer 1
16 80-125-00 Pinion Bearing Race 2
18 41-707-50 Differential Bearing Adjuster Nut 2
19 88-080-04 5/16” X 3/8: NC Hex Bolt 2
20 88-140-16 1/2” X 2” Hex Bolt 2
21 96-243-00 7/16” X 7/8” Hex Bolt (Locking Head) 10
