Replacement Parts
Page 97
* Not available at time of printing
ME-45X-01
E-451 & E-457
Transaxle Chain Case
ITEM# PART # DESCRIPTION QTY
1 88-109-61 3/8” SAE Flat Washer 3
2 97-100-00 Woodruff Key 1
3 88-087-11 Chain Adjusting Screw 1
4 88-069-80 5/16” NC Hex Nut 1
5 88-103-09 Motor Mounting Screw, 3/8” X 3/4” NC 4
6 80-703-00 O-Ring, 4-1/2” ID X 5” OD 1
7 70-454-00 Motor Mounting Plate 1
8 88-109-87 3/8” KEPS Nut 3
9 30-070-00 15 Tooth Double Motor Sprocket 1
10 16-415-00 Spacer Main Sprocket 1
11 30-070-11 60 Tooth Double Pinion Sprocket (E 4-51) 1
30-070-10 81 Tooth Double Pinion Sprocket (E 4-51, E 4-57) 1
12 30-320-11 Drive Chain, 15-81 T Double Sprocket (E 4-51, E 4-57) 1
30-320-12 Drive Chain, 15-60 T Double Sprocket (E 4-51) 1
13 44-352-52 Backing Plate, Gear Case 1
14 88-101-13 3/8” X 1-1/4” NC Hex Bolt 5
15 88-080-20 5/16” X 3” Hex Bolt 9
16 41-989-00 Drain and Fill Plug 2
17 43-201-11 Chain Cover 1
20 45-331-00 Pinion Oil Seal, Gear Case 1
21 97-250-00 Pinion Nut 1
22 88-089-81 5/16” NC Locknut 12
23 88-088-61 5/16” SAE Flat Washer 3
24 88-108-63 Internal Tooth Lock Washer 5
25 88-239-82 Motor Nut, 3/4” NF Hex Jam Nut, Thin 1
