TC Electronic SYSTEM 6000 MKII Algorithm Manual

17
vss™-M4
Levels page
In Level (Reverb 1 to 4)
Range: Off to 0dB
Individual input level of the four reverbs. If the input signal
is close to full scale and/or long decay times are used, it
may be necessary to attenuate the input to avoid overload.
Reverb Level (Reverb 1 to 4)
Range: Off to 0dB
Individual reverb (wet) level of the four reverbs.
Note: This parameter is also available on the Rev.1 to 4
sub pages.
Dry Level (Reverb 1 to 4)
Range: Off to 0dB
Individual dry signal level of the four reverbs.
In send/return configurations, the parameter should be set
to Off.
Output Level (Reverb 1 to 4)
Range: Off to 0dB
Individual output level of the four reverbs.
Reverb pages 1-4
Reverb
Master Decay (Reverb 1 to 4)
Range: 0.1 to 20s
Individual Decay parameters of the four reverbs.
This parameter is also available on the Main page.
Reverb Diffuse
Range:-50to+50
This parameter offsets the diffusion away from what is
considered optimum for a given Decay time.
Build
Range:Fast,Slow
Selectsthespeedofthebuild-up(ie.attack)ofthereverb.
Reverb Type (Reverb 1 to 4)
Select between different reverb types for each of the four
reverbs. By selecting different types or different version (A,
B, C, D), de-correlated responses are ensured.
This parameter is also available on the Main page.
Reverb Lo/HiCut
Lo Cut
Range: 20Hz to 200Hz
Determines the Lo Cut frequency. Attenuation amount is
controlled via the Lo Damp parameter.
Lo Damp
Range: 0 to -18dB
Attenuation amount of frequencies below the Lo Cut
setting.
Hi Cut
Range:20Hzto20kHz
Determines the Hi Cut frequency.
