TC Electronic SYSTEM 6000 MKII Algorithm Manual

30
vss™ 6.1 - rEvErb
Reverb Diffuse
Range:-50to+50
Offsets the diffusion away from the default of a given
Decaytime.Foroptimumperformance,thediffusionis
automaticallyadjustedwhenDecayischanged.
Reverb Size
Range:0to15
AdjuststheoverallperceivedsizeoftheDiffuseFieldpart
of the response. It affects the spread and correlation of the
diffused response, not the decay time. The default value
depends on the Location Type chosen.
Reverb Type
Range: Normal/ Colored
When a Location Type is selected, a Reverb type is
automaticallyset.WiththeReverbTypeparameterit’s
possible to select between the most natural sounding
Diffuse field (Normal) and a more colored, glossy Diffuse
field setting.
Channel Decay
The following parameters are Decay multipliers for the
diffuse responses. The multipliers relate to the Master
Decaytime.Example:IftheDecaytimeissetat2seconds
andamultiplierissetat0.5,theactualDecaytimeofthe
selected channel is 1 second.
Left
Range: 0.1 to 2.0
Decay multiplier for the Left channel.
Center
Range: 0.1 to 2.0
Decay multiplier for the Center channel.
Right
Range: 0.1 to 2.0
Decay multiplier for the Right channel.
Left Surround
Range: 0.1 to 2.0
Decay multiplier for the Left Surround channel.
Right Surround
Range: 0.1 to 2.0
Decay multiplier for the Right Surround channel.
Center Surround
The diffuse part of the Center Surround channel is based
upon the Left and Right Surround multiplier settings.
Gloss
Reverb Modulation
Modulation Type
Range:Off,Default,Front/Rear,Front/RearSubtle,Front
RearDiffuse,Left/Right,Clockwise,CenterClockwise,
Chaos or Sync. Select between different types of
Modulation on the diffused response.
Mod Rate
Range:-50to+50
Offsets the speed of the modulation away from its default.
Mod Depth
Range: 0 to 200
Offsets the Depth of the modulation away from its default.
Early Reflections
- working for You
Introduction
System6000internallyrenderscomplexEarlyReflection
patternswithmuchhigherdirectionalresolutionthana5.1
or6.1speakerset-upcandiscretelyprovide.Eventhough
all reflection patterns are minutely calculated and tuned, it
can be useful to scale down their complexity to integrate
the room simulation as seamlessly as possible for a given
source material.
VSS-6.1 Reverb therefore offers different means of
reducingthefullpatterns,makingeachpatterneasyto
tailor for a wide range of applications.
Restrictions in Time
-EarlyStartandEarlyStop
TheEarlyStartandEarlyStopparametersprovide
adjustmentsofwhenreflectionswillstartandwhenthey
will end.
Front & Surround Restriction - Restrictions in Direction
Range-FrontRestriction:22,30,45,90degrees
Range-SurroundRestrictions:90,115degrees
By giving weight to certain directions of arrival, the user
can dramatically change the way a given reflection pattern
is perceived. In System 6000, the distinction between
incoming reflections can be controlled in a frontal, lateral
and dorsal zone as shown on the illustration above. On
