TC Electronic SYSTEM 6000 MKII Algorithm Manual

84
EQ - 5.1
Type Selector
• PressType and use faders 1-4 to select filter types.
ForLoandHifiltersselectbetweenfiltertypes: 
Parametric, Notch, Shelve and Cut.
ForMid1andMid2filtersselectbetweenfiltertypes:
Parametric and Notch.
Parametric Filter - Broad type
Shelving Filter
Notch Filter - Narrow Type
Cut Filter - Bessel type
Cut Filter - Butterworth type
Freq
Press FreqanduseFaders1to4toadjustfrequencefor
each of the four bands.
Range-Loband :20Hzto20kHz
Range-Mid1band:20Hzto20kHz
Range-Mid2band:20Hzto20kHz
Range-Hiband :20Hzto40kHz
Gain
Press GainanduseFaders1-4toadjustgainforeachof
thefourEQbands.
Range for the Parametric, Shelve and Cut type:
LoGain  :-12dBto+12dB
Mid1Gain :-12dBto+12dB
Mid2Gain :-12dBto+12dB
HiGain  :-12dBto+12dB
Range for the Notch filter:
Lo Gain : -100dB to 0dB
Mid1 Gain : -100dB to 0dB
Mid2 Gain : -100dB to 0dB
Hi Gain : -100dB to 0dB
