TC Electronic SYSTEM 6000 MKII Algorithm Manual

9
vss
TM
3
Rev Balance
Range: -100dB R, center, -100dB L
The left/right balance of the Reverb. Allows you to offset the
diffuse field from the normal center position.
Diffuse
Range:-50to+50
This parameter gives you more or less diffusion than the
algorithmdesignerintendedforthegivenDecaytime.For
optimumperformancethediffusionisautomaticallyadjusted
behind the scenes whenever you change Decay times.
This parameter gives you the added control to vary the
diffusion around this automatic setting.
Decay/Crossover
Lo Decay
Range:0.01to2.5
Multiplier for the frequencies below the Lo Xover frequency.
Example:IftheMainDecayparameterissetto2.0secand
theLoDecayparameterissetto1.5,frequenciesbelow
the Lo Xover will decay for 3.0 sec.
Converselyifthisparameterissetto0.5theDecaytime
below the Lo Xover point will be only 1 sec.
Lo Xover
Range:20Hzto500Hz
Sets the frequency at which the transition from the low to
thelow-midfrequenciestakesplace.
Lo Mid Decay
Range:0.01to2.5
The Ratio control multiplier for the low-mid frequencies.
Mid Xover
Range:200Hzto2kHz
Sets the frequency at which the transition from the low-mid
tothemidfrequenciestakesplace.
Hi Mid Decay
Range:0.01-2.5
The Ratio control multiplier for the mid frequencies. This
parameter is normally set to 1.0 as it is the main parameter
adjustedbythemainDecayparameter.Thismid-range
decay control would normally be omitted, however, TC
Engineersfeltyoucouldusethisparameterasafine
adjustmenttoolto“tweak”apresettosoundjustright
withouthavingtoadjustthemasterDecayparameter.
Hi Xover
Range:500Hzto20kHz
Sets the frequency at which the transition from the mid
frequenciestothehighfrequenciestakesplace.
Hi Decay
Range:0.01to2.5
Multiplier for the frequencies above the Hi Xover frequency.
Example:IfthemainDecayparameterissetto2.0secand
theHiDecayparameterissetto1.5,frequenciesabove
the Hi-Xover will decay for 3.0 sec. Conversely if this
parameterissetto0.5theDecaytimeabovetheHiXover
point will be 1 sec.
Modulation
Reverb Modulation
RevMod Type
Off, Smooth 1, Smooth 2, Perc, Wow, Vintage, Wild
Selects the type of modulation.
RevMod Rate
Range:-100,default,+100
AllowsyoutooffsetthespeedoftheLFOfromthefactory
default assigned to each Type.
RevMod Width
Range: 0% to 200%
Sets the Width of the modulation.
Space Modulation
SpcMod Type
(Off,Normal,Fast,Slow,MidFreq,Sync)
Selects the type of Space Modulation.
SpcMod Rate
Range:-100,default,+100
AllowsyoutooffsetthespeedoftheLFOfromthefactory
default assigned to each type.
SpcMod Width
Range: 0 to 100%
Sets the width of the modulation.
SpcMod Depth
Range:-50,default,+50
Allows you to offset the amount of space modulation from
the factory default.
