TDK-Lambda GH10-150 - Program Subsystem

108
OUTPut:RELay2[:STATe] <Bool>
Function Sets PROG_OUT_2 pin (J1-20) in a rear panel connector. 0 – MOSFET is ON.
1 – MOSFET is OFF.
Parameter
0|1, OFF|ON
Query
OUTPut:RELay2[:STATe]?
Return
<Bool> 0|1
OUTPut:TTLTrg:MODE <DSC>
Function
Sets the operation mode of the Trigger Out signal to OFF, FSTR, or TRIG
mode.
Programming Mode - NONE:
• In TRIG mode, a trigger is generated if output state changes.
• In FSTR mode, an output pulse is generated automatically any time an
output parameter, such as output state, voltage, or current is
programmed.
Programming Modes - LIST or WAVE:
• In TRIG mode, a trigger is generated if LIST or WAVE has completed.
• In FSTR mode, an output pulse is generated automatically any time a
step has completed.
Parameter
0|1|2, OFF|FSTR|TRIG
Query
OUTPut:TTLTrg:MODE?
Return
<DSC> OFF|FSTR|TRIG
4.14.7 Program Subsystem
[PROGram]:COUNter <NR1> | INFinity
Function
Sets the sequencers' iterations counter
Parameters 1 ~ 9999. Any number greater than 9999 is interpreted as INFinity.
Use INFinity if you wish to execute a sequence indefinitely.
Query
[PROGram]:COUNter? (if COUNter > 9999, the response is INF)
Return
<NR1>| INF
[PROGram]:LIST:CURRent <NRf+>,{<NRf+>}
Function Specifies the output current points in a list.
Current points are separated by commas.
The function accepts up to 100 parameters.
Parameters
The range is limited by the power supply current programming range.
Unit
A
Query
[PROGram]:LIST:CURRent?
Return
<NR2>,{<NR2>} 5-digits format.
Example
LIST:CURR 2.5,3.0,3.5; LIST:CURR MAX,2.5,MIN
NOTE
A delay of ~100mSec is required after the [PROGram]:LIST:CURRent command if long
sequences are used, prior sending any additional command.
