4.14.8 Source Subsystem
[SOURce]:CURRent:EXTernal:LIMit[:STATe] <Bool>
Function Enables/disables the current limit in the analog source control mode.
If enabled, the analog current programming range by the rear panel is
limited to a digital current programming value.
Refer to section 5.7 for additional information explaining OCL – Analog
Programming Over Current Limit.
Parameter
0|1, OFF|ON
Query
[SOURce]:CURRent:EXTernal:LIMit[:STATe]?
Return
<Bool> 0|1
[SOURce]:CURRent:EXTernal:MODE <DSC>
Function Sets the current programming source: Front panel/Communication (Digital),
external voltage, or external resistor.
Parameter
0|1|2 or DIG|VOL|RES
Query
[SOURce]:CURRent:EXTernal:MODE?
Return
<DSC> DIG|VOL|RES
[SOURce]:CURRent[:LEVel][:IMMediate][:AMPLitude] <NRf+>
Function
Sets a digital programming output current value.
Parameter
The range is limited by the power supply model
Unit
A
Query
[SOURce]:CURRent[:LEVel][:IMMediate][:AMPLitude]?
Return
<NR2> 5-digits format
Example :CURR? returns the present programmed current level.
:CURR? MAX and :CURR? MIN return the maximum and minimum
programmable current level.
[SOURce]:CURRent:SLEW:DOWN <NRf+>
Function
Sets a digital current reference down programming slew rate.
Parameters
0.0001 ~ 999.99
Unit
A/mS
Query
[SOURce]:CURRent:SLEW:DOWN?
Return
<NR2>
Example :CURR:SLEW:DOWN 1 Sets digital current reference down programming
slew to 1A/mSec.
:CURR:SLEW:DOWN? returns a digital current down programming slope
value.
:CURR:SLEW:DOWN? MAX and :CURR:SLEW:DOWN? MIN return the
maximum and minimum digital current reference down programming slope
value.
