NOTE
If the Sequencer function is enabled (INITIATE STATE), the Internal Resistance, Constant Power
Limit, Slew-Rate and Analog Programming functions are disabled.
NOTE
If the Internal Resistance, Constant Power Limit, Slew-Rate or Analog Programming functions are
enabled, the Sequencer function is disabled.
5.1.4 Sequencer Setting Memory
Refer to Table 5-1 for memory parameters stored/loaded using Sequencer Store/Load functions.
Function
Factory Reset
(Default Settings)
Store & Load
Sequence Mode (LIST/WAVE)
None
+
LIST/WAVE Sequence Voltage/Current values
0
+
LIST/WAVE Sequence Dwell/Time values
0
+
Step
AUTO
+
Counter
1
+
Continuous
1
+
Initialize
Not Initialized
-
Trigger In Source
BUS
-
Trigger In Delay
0
+
Trigger Out Mode
OFF
-
Table 5-1: Sequencer Memory Parameters
5.2 Trigger System
The Trigger system, consisting of Trigger In and Trigger Out functions, provides the ability to
synchronize sequencer arbitrary waveforms. In addition, the Trigger Out function provides the
ability to generate trigger signal, if power supply output state or voltage / current programming
value has changed.
5.2.1 Trigger Initialize
Trigger In initialization is required to activate Trigger In function. The activation is available via the
Front Panel (refer to section 1.8) or the communication command INITiate[:IMMediate].
If continuous re-initialization is required, activate the system to be able to receive Trigger In signal
continuously via the Front Panel (refer to section 1.8) or the communication command
INITiate:CONTinuous <Bool>. Continuous re-initialization allows immediate triggering, thus
preventing the need for re-initialization.
