12. GENERAL MAINTENANCE EO1-11148
12.1 Removing Jammed Paper
12- 1
12. GENERAL MAINTENANCE
12.1 Removing Jammed Paper
1. Turn the Control Lock to the OFF position using the Mode
Selector Key.
2. To remove the Printer Cover, inset the Printer Cover Key to
the Printer Cover Lock, and then turn it clockwise.
3. Open the Cutter Unit when the paper jam occurred in the
Receipt Printer. Move the Paper Free Lever in the
direction of the arrow, and remove the jammed paper.
4. Return the Paper Free Lever in position. Close the Cutter
Unit for the Receipt Printer.
Re-load the Paper Roll. (Refer to Section 8 INSTALLING
AND REPLACING THE RECEIPT AND JOURNAL
ROLLS.)
WARNING!
Care must be taken not to injure yourself with the paper cutter.
