4. PROGRAMMING OPERATIONS EO1-11148
4.1 Basic Key Functions
4- 2
4.1 Basic Key Functions
1) Main keys
[#/NS] ----------------- Used to enter the Program Submode No., Address data, Item data.
Used to end the entire Program Submode Sequence.
[ST], [AT/TL]-------- Used to enter the Address No., Item Code.
Used to end the Item data entries.
2) [C] key
• When the program data has finished to be printed, the [C] key cannot clear it. If you correct the
program data, re-enter the data.
• Before the program data is printed, the [C] key can clear it.
3) [ITEM CORR] key
When you enter incorrect settings, depressing the [ITEM CORR] key can return the display to the
previous item setting.
4) To clarify the operation flow, definitions of keys of the ECR keyboard are as shown below.
|
|--------Selective numeric value which is entered through the Numeric keys.
[ ] --------Depression of the function key.
xxxx
-----------Fixed numeric value which is entered through the Numeric keys.
Fixed
