4. PROGRAMMING OPERATIONS EO1-11148
4.14 Footer Message Programming (Submode 31)
4-22
4.14 Footer Message Programming (Submode 31)
A Footer message (max. 120 characters; 24 characters x 5 lines) to be printed on the footer portion of
receipt can be programmed here.
Anytime outside a sale
Control Lock: SET
31 [#/NS] |Line No.
| [#/NS] Character entry [AT/TL] [#/NS]
NOTE: Entering 2 digits of numeric code provides an alphanumeric character of Footer message.
Therefore, odd number of numeric digit entry will cause an error. When less than 48 digits
of numeric data are entered, this ECR uses space code entry. If a Footer message
includes spaces at the beginning, entering space code is required at the beginning of data
entry. For the Footer message, up to 24 regular-sized or 12 double-sized characters can
be entered. Also a combination of both types can be entered.
Example) To program the following Footer message
4.15 Function Key (Combination Key) Setting (Submode 34)
A string of key opeartions can be set on each FUNCTION key ([FUNCTION 1] to [FUNCTION 10]).
Using such programmed [FUNCTION] keys, the operator can eliminate time in various routine
operation procedures. (Up to 10 strokes of key operations can be set to each [FUNCTION] key.)
Anytime outside a sale
Control Lock: SET
34 [#/NS] [FUNCTION] [KEY]………[KEY] [FUNCTION] [#/NS]
OPERATION
CONDITION
2 digits (01 to 05)
Max. 24 characters
(See NOTE below.)
Repeat for other lines.
Line No. 1
Line No. 2
Line No. 3
Line No. 4
Line No. 5
B a r g a i n s a l e s o n e v e r y
T u e s d a y .
C o m e t o s ave money!
OPERATION
CONDITION
Depress one of the
[FUNCTION] keys.
(FUNCTION 1 to
FUNCTION 10)
Depress the keys to be
contained in the key string.
(Max. 10 strokes)
Repeat for other FUNCTION keys.
Depress the same
FUNCTION key that
was depressed at the
declaration.
To Next Page
