Technicolor COM3000 User Manual

w w w . t e c h n i c o l o r . c o m / m c s
Page 44
Bitrate - Figure 29 shows the Bitrate field.
➢ Displays a snapshot of the bitrate at the QAM20 port associated with the selected QAM
major/minor channel. In the example QAM ch 33-2 is streaming 5.9 Mbps.
➢ If the stream is not routed to a COM20 card the Bitrate will read 0.0.
Figure 29 - Bitrate Display
SNR and Strength - Figure 30 shows the SNR and Signal Strength Display.
➢ The signal to noise ratio for the tuned channel. If the SNR is 10 or below, the block will be
highlighted yellow.
➢ Strength displays the relative signal strength for the tuned channel in dBm. If the strength is -
50dBm or below the block will highlighted yellow.
Figure 30 - SNR and Signal Strength
