Page 64
24.13
Using the COM51
“Simulcrypt” Feature
Simulcrypt is not currently supported on COM51.
➢
To facilitate LYNK
or other 3
rd
party DRMs submi
t a request t
o DIRECTV to disabl
e Pro:Idiom
encryption.
24.14
Displaying COM3000 Status
By clicking the Display hy
perlink at the top of an
y COM3000 web interface page, you can see
the information last displayed on the Discover Screen
.
63
65
