TechniSat DIGITRADIO 1 User Manual

11
Do not expose the device to dripping or sprayed water. If water gets into the
device, switch it off and contact the service department.
Do not expose the device to sources of heat that will heat it up in addition to
normal use.
The device should be disconnected from the mains in the event of a storm.
Overvoltage can damage the device.
If there is an obvious problem with the device, or a smell or smoke is produced,
or there is a significant malfunction or damage to the housing, switch the
device off and contact the service department.
Only connect the device to a mains voltage at 100V-240V~, 50/60 Hz using the
mains adapter.
Never try to operate the device at a different voltage.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
