TechniSat DIGITRADIO 1 User Manual

37
piece of music can be filtered out of the signal being broadcast. This leads to a reduction
of data in the data stream to be transmitted, with no detectable sound difference for
the listener (HE AAC v2 - process for enhancing the DAB+ encoding process).
7.1.2 Audio stream
With digital radio, audio streams are continuous data streams that contain MPEG-1
Audio Layer II frames and represent acoustic information. They are used to broadcast
normal radio programmes, which you can listen to on the receiver. Digital radio not
only provides radio with excellent sound quality, but additional information as well.
The information may be about the current programme or something else (e.g. news,
weather, traffic and tips).
7.2 DAB+ (digital radio) reception
> Press the DAB+/FM button until [DAB] is shown in the display.
If DAB+ is being launched for the first time, a full station scan will take place.
When the scan has finished, the first station in alphanumeric order will be played.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
