TechniSat DIGITRADIO 1 User Manual

39
7.2.3 Storing DAB+ stations in a storage location
The programme memory can store up to 20 stations in the DAB+ range.
> First select the station you want (see Section 7.2.2).
> To save this station to a storage location, hold the FAV button down while the
station is playing. Then use the t and u buttons to select a station storage
location (1 - 20). Press the OK button to save it.
> Repeat the process to save more stations.
The station stored in FAV storage location 1 can also be accessed via the direct
selection button.
7.2.4 Accessing DAB+ stations in a storage location
> To access a station that you have already saved in the FAV memory, briefly
press the FAV button and use the t and u buttons to select a station storage
location (1 - 20). Press the OK button to play the station.
If no station has been saved to the selected storage location, [(none)] appears
in the display.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
