TechniSat DIGITRADIO 1 User Manual

52
9.2 Display brightness
You can set the display brightness for both operation and standby (only available if
the radio is connected to the mains).
> To do so, press the MENU button and use the t or u buttons to select the
[Brightness] entry.
> Press the OK button.
> Use the t or u buttons and then press the OK button to select one of the
following functions:
[Operation] controls the brightness in normal operating mode. Here you can
select from among the [High], [Medium] and [Low] brightness levels. Use the
t or u buttons to select a brightness level and press the OK button to save
this. The setting applies to both mains and battery operation.
[Standby] controls the brightness in standby mode (only applicable when the
radio is connected to the mains). Here you can select from among the [High],
[Medium] and [Low] brightness levels. Use the t or u buttons to select a
brightness level and press the OK button to save this.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
