TechniSat DIGITRADIO 1 User Manual

31
5.4 General device functions
5.4.1 Switching the device on
> To ensure good DAB+/FM (VHF) reception, please fully remove the aerial located
on the reverse of the device. Please also note Section 5.3.3 when doing so.
> First prepare the DIGITRADIO 1 for operation as described in Sections 5.3.1 and 5.3.2.
> Press the On/Standby button on the top of the device to switch the DIGITRADIO 1 on.
After switching the device on for the first time, you must set the [language].
To do so, use the t or u buttons to select one of the available languages and
confirm the selection by pressing the OK button. The device then automatically
runs a full scan in DAB mode. The display information shows the progress
during the scan, plus the number of digital radio stations found. The first DAB+
station is played after the scan has finished.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
