TechniSat DIGITRADIO 1 User Manual

9
3.1.1 Intended use
The device has been developed to receive DAB+/VHF radio broadcasts. The device is
designed for personal use and is not suitable for commercial purposes.
3.2 Important instructions
Please observe the following instructions to minimise any safety hazards, prevent
damage to the device, and help protect the environment.
Please read all the safety instructions carefully and store them for future reference.
Always follow all the warnings and instructions in this instruction manual and on
the rear of the device.
Warning - indicates an important note that you must always observe in order to
avoid problems with the device, loss or abuse of data or unwanted operation.
Tip - indicates a note about the function described as well as other functions
associated with it and any others to be observed with reference to the
respective place in the instruction manual.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
