TechniSat DIGITRADIO 1 User Manual

49
> The next numbers for the time then flash (minutes); these can also be changed
as described above.
> After each setting, press the OK button to move on to the next setting.
> Proceed with setting the date as described above.
> Once all the settings have been carried out and the OK button has been
pressed for the last time, [Time Saved] appears in the display.
9.1.2 Updating the time
In this submenu you can specify whether the time should update automatically via
DAB+ or FM (VHF) or you want to enter it manually (Section 9.1.1).
> Press the MENU button and use the t or u buttons to select the [Time]
submenu.
> Press the OK button.
> Use the t or u buttons to select the [Time Updates] entry, then press OK.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
