TechniSat DIGITRADIO 1 User Manual

35
6 Menu operation
You can access all the functions and settings for the DIGITRADIO 1 via the menu.
The MENU, t, u and OK buttons are used for menu navigation.
The menu is split into submenus, each of which contains various menu items or
functions that can be activated depending on the mode (DAB+ or FM). Simply press
the MENU button briefly to open the menu. To switch to the submenus, first press the
t or u buttons to display a submenu and then press the OK button to access the
submenu. An asterisk (*) marks the current selection.
Closing the menu: Press the MENU button several times (depending on which
submenu you are in) until the current radio station is displayed again.
Settings are only saved if the OK button has been pressed. If the MENU button
is pressed instead, the settings are not accepted and saved (the MENU button
takes on the function of a “Back” button here).
Functions and the buttons to be pressed are shown in bold in the operating
manual. Displays are in [square brackets].

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
