TechniSat DIGITRADIO 1 User Manual

26
5.3 Preparing the DIGITRADIO 1 for use
5.3.1 Inserting the battery
> Open the battery compartment at the back of the device by pushing the
battery compartment cover in the direction of the arrow marked on the side.
Then remove the cover.
> Insert the DIGITRADIO 1 battery, paying attention to the alignment of the gold contacts
with one another. Push it under the plastic guide within thebattery compartment.
The DIGITRADIO 1 battery can also be purchased separately in retail outlets.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
