TechniSat DIGITRADIO 1 User Manual

33
5.4.3 Switching between DAB+ and FM mode
> Use the DAB/FM button to switch between DAB+ (Digital Radio) and FM (VHF).
5.4.4 Setting the volume
> Set the volume using the Volume +/- buttons. The set volume is displayed via
a bar diagram. Please also note Section 5.3.4 on operation with headphones
attached.
5.4.5 Display
Depending on the function or option selected, the following information is shown in Display:
Stationname,
frequency,
menu name
Display, menu
options, volume
Battery
charge status

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
