TechniSat DIGITRADIO 1 User Manual

36
Some text descriptions (e.g. menu items, broadcaster information) may be too
long to appear in the display. These will then be shown as scrolling text after a
few moments.
7 The DAB+ (digital radio) function
7.1 What is DAB+?
DAB+ is a new digital format that delivers crystal-clear sound with no background
noise. In contrast to traditional analogue radio stations, DAB+ can be used to
broadcast multiple stations on one and the same frequency. These are called
ensembles or multiplexes. An ensemble consists of the radio station and several
service components or data services that are broadcast by the radio stations. You can
find out more at www.digitalradio.de or www.digitalradio.ch, for example.
7.1.1 Data compression
Digital radio exploits aspects of human hearing for data compression. The human ear
does not detect sounds that are below a certain minimum volume. Data below the
absolute threshold of hearing can therefore be filtered out. This is possible because
the digital data stream also saves the relative volume of each unit of information to
other units. At a specific threshold, the quieter parts of a sound signal are blocked
out by the louder parts. All the sound information below the threshold of hearing in a

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
