TechniSat DIGITRADIO 1 User Manual

30
5.3.4 Using headphones
Damage to hearing!
Do not listen to the radio at high volume with headphones. Doing so can cause
permanent hearing damage. Turn the radio volume down to a low volume before
using headphones.
Only use headphones with a 3.5 mm stereo jack plug.
> Insert the headphone jack into the headphone socket on the side of the
device. Sound is then played exclusively via the headphones and the speaker is
switched to mute.
> If you would like to use the speakers again, unplug the headphones from the
headphone jack on the device.
If you want to set the volume to maximum, the message [Warning! Loud
Volume! OK?] appears shortly before the maximum volume is reached. Confirm
the message by pressing the OK button. You can then adjust the volume to the
maximum possible level. The setting is stored until the device is next switched
off/on.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
