TechniSat DIGITRADIO 1 User Manual

48
9 System settings
All the settings described in this section apply equally to DAB+ and FM mode.
9.1 Setting the time and date
9.1.1 Setting the time/date manually
Depending on the time update setting (Section 9.1.2), you will need to set the time
and date manually.
> Press the MENU button and use the t or u buttons to select the
[Time] submenu.
> Press the OK button.
> Use the t or u buttons to select the [Set Time/Date] entry and press OK.
> The first numbers for the time flash (hours); these can be changed using the
t or u buttons.
The u button increases the value, and the t button reduces the value.
> Press the OK button to accept the setting.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
