TechniSat DIGITRADIO 1 User Manual

45
8.4 Manual station scan
> Press the t or u buttons multiple times to set the station or frequency you want.
The display shows the frequency in increments of 0.05 MHz.
8.5 Scan settings
The sensitivity of the scan can be set in this menu item.
> Press the MENU button and use the t or u buttons to select the [Scan
Settings] entry, then press OK.
> Select whether the scan should only stop at stations with a strong signal
[Strong Stations Only] or at all stations (including ones with weak signals)
[All Stations].
With the All Stations setting, the automatic scan stops every time an available
station is found. This can lead to weak stations with background noise being
played. During commissioning and when applying the factory settings, the
[All Stations] menu item is set by default.

TechniSat DIGITRADIO 1 Specifications

General

Package type	Box
Package depth	50 mm
Package height	170 mm
Package weight	514 g
Projection	-
Antenna type	External
Product color	Black, Silver
Headphone outputs	1
Headphone connectivity	3.5 mm
RMS rated power	1 W
Storage temperature (T-T)	5 - 90 °C
Operating temperature (T-T)	5 - 35 °C
Battery capacity	1050 mAh
Battery life (max)	10 h
Input voltage	230 V
Power supply input voltage	5 V
AC input frequency	50 Hz
Display type	OLED
Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Cables included	USB

Weight and Dimensions

Depth	31 mm
Width	155 mm
Height	91 mm
Weight	276 g
