Technogym EXCITE Run 700 - Page 25

RUN EXCITE-2008: Service & Maintenance Manual - rev. 1.3
Page 2.13
TRM-20: Low Driver-Display communication and power supply cable
(Patch connector – Display Board – Patch connector)
Display Board
Patch conn.
C
Signal Color
CN7 CN6
Patch conn.
A
2 Gnd +12 Vdc Gray 2 - -
3 Gnd +5 Vdc Black 3 - -
4 -sensing +5 Vdc White 4 - -
6 +12 Vdc Orange 6 - -
7 +5 Vdc Red 7 - -
8 +sensing +5 Vdc Yellow 8 - -
9 Emergency Purple - 4 -
10 Reset Blue - 5 -
11 +12 Vdc isolated Red - 1 -
Black - 6 -
12 Gnd +12 Vdc isolated
Black - - 1
- HW Emergency Gray - 2
- SW Emergency Gray - 3
2
Patch conn.
B
Signal Color
Display Board
CN2
1 NC Green-White 1
2 NC Green 2
3 Digital Gnd Orange-White 3
4 Download Blue 4
5 Reset Blue-White 5
6 Digital Gnd Orange 6
7 485 Tx/Rx + Brown-White 7
8 485 Tx/Rx - Brown 8
TRM-29: Joystick cable
(Display Board/CPU – Micro Joystick (↑/↓ or +/-))
Display Board:
CN11/CN13
CPU board:
CN26/CN27
Signal Color
Micro
↑/+
Micro
↓/-
1 Value 1 reference White - C
2 Value - (incline ↓ or speed -) Brown - NA
3 Value 2 reference Green C -
4 Value + (incline ↑ or speed +) Yellow NA -
