RUN EXCITE-2008: Service & Maintenance Manual - rev. 1.3
Page 2.14
TRM-31: CSafe cable board
(Display Board – CSafe Board)
Display Board
CN1
Signal Color
CSafe Board
CN1
1 Digital #1 Flat cable 1
… … … …
14 Digital #14 Flat cable 14
TRM-32: TGS reader Signal Cable
(Display Board/CPU – TGS reader)
Disp. Board: CN3
CPU board: CN8
Signal Color
TGS reader
CN1
1 +12 Vdc power supply Yellow 1
3 Rx White 8
5 Tx Green 7
9 Gnd Brown 3
TRM-54: Limit Switch cable
(ALE/AT UL Driver – Linit Switch)
ALE/AT UL
driver
J8
Signal Color Limit Switch
3 Contact White Faston
8 Reference Brown Faston
To Next Page
