Technogym Top 600 XTPRO - Page 14

TOP 600 XTPRO: Service & Maintenance Manual - rev. 2.0
Page 2.4
TX-3/L: High voltage power supply cable
Power input socket – Filter
Power entry Signal Color Filter
Faston Live Blue Faston
Faston Neutral Black Faston
Faston Ground Yellow-
green
Faston
BX-4/L: High voltage power supply cable
Filter – Power supply
Filter Signal Color Power supply
CN1
Faston Live Blue 4
Faston Neutral Black 6
TX-5/L: Alternator cable
Alternator interface board – Alternator – Resistor
Alternator
interface board
CN2
Signal Color Alternator Resistor
1 Alternator RPM X 6 Violet Red
eyelet 4
-
2 Resistor - Blue
Blue
Yellow
eyelet 6
Yellow eyelet 4
3 Resistor + Red
Red
Yellow
eyelet 6
5 Ground Black -
Yellow
eyelet 4
4 Excitation Orange Red Faston
RT-6/L: Low voltage power supply cable
Power supply – Alternator interface board
Power supply
CN2 FG
Signal Color Alternator
interface board
CN3
2 + 5 Vdc Yellow 4
3 Ground Black 3
4 Faston Ground Yellow -
5 + 12 Vdc Red 2
